Van den Hul MC - Silver IT 65 G Interconnect RCA
Van den Hul MC - Silver IT 65 G Interconnect RCAtransmission quality. The shielding has, beside 40 3T conductors, 2 layers of multiple, heavy silver coated, high quality copper strands.
The dynamic sound character combined with the very high resolution will be a very big surprise for you. All our combined and innovative 3T technology contributes to a very natural sound reproduction never
experienced before.
The 3T The Sea Hybrid is a coaxial interconnect with technical upgrades compared to the 3T The River Hybrid. The single Hybrid centre conductor is made of a thicker 3T single strand conductor with 400 micron diameter and coated with a L.S.C. layer to improve the signal
transmission quality. The shielding has, beside 40 3T conductors, 2 layers of multiple, heavy silver coated, high quality copper strands.
The dynamic sound character combined with the very high resolution will be a very big surprise for you. All our combined and innovative 3T technology contributes to a very natural sound reproduction never
experienced before.
| Color: Purple |
| Brand: Van den Hul |
| Quality class product: High-end |
Description
With the MC – Silver IT 65 G all manufacturing handling is done with extreme care and maximum attention is paid to maintaining a very constant characteristic impedance along the whole cable, as well as in the micro domain, to prevent signal reflections even up to very high frequencies. The centre lead consists of 19 extremely high-grade Matched Crystal (MC) extruded OFC strands with a very thick and dense extruded Matched Crystal (MC) purest silver coating applied in a mechanical processing step. The diameter of this centre conductor is: 1.4 mm. The centre lead resistance is remarkably low: 1.43 Ohm/100 m. The typical capacitance is: 81 pF/meter. The insulation between the core and shielding is made of Teflon tape in several layers exhibiting a typically low relative dielectric constant of 1.4. The double shielding is made of 96 x 0.10 mm. Matched Crystal (MC) OFC wire braiding with a very thick and dense coating of very pure silver underneath a helically overlapping wound of very pure 2.5 x 0.05 mm. silver ribbon. The external insulation is made of the special purple Hulliflex ® EHD material. This specific insulation material is too costly to be used in all our products. | MC – Silver IT 65 G exhibits an extremely extended frequency range of 65 GigaHertz. Precautions must be taken to prevent bending around a very small radius. The minimum safe value of the bending radius is 58 mm. The external diameter of the MC – Silver IT 65 G is: 5.8 mm.; a size that perfectly matches our 5.5 mm gold RCA connector. Conductor 19 extremely high-grade Matched Crystal (MC) extruded OFC strands with a very thick and dense extruded Matched Crystal (MC) purest silver coating applied. Jacket The transparent purple Hulliflex® EHD jacket, exclusively used for our MC - Silver series interconnects, provides even more protection and durability. Shielding The shielding consists of Matched Crystal (MC) OFC wire braiding with a very thick and dense coating of very pure silver, and a helically overlapping wound of very pure 2.5 x 0.05 mm. silver ribbon. Purpose High-quality (unbalanced) line-level audio interconnect with stunning dynamics, vivid clarity, and extremely layering in its signal transmission. |
Specifications
Type kabel - Analoge interconnect, ongebalanceerd
Beschikbare uitvoeringe - RCA
Kleur van de mantel - Paars
Productassortiment - Premium bereik
Geleider materiaal - Verzilverd OFC
Geleiderdiameter - 0,4 mm
Afscherming - Dubbel afgeschermd
Kabeldiameter - 5,8 mm
Weerstand - 0,0143 Ω/m (geleider)
Capaciteit - 81 pF/m
